TRC - LWM Wattage

Order	Milliamps	TRC-LWM-1-16L	TRC-LWM-2-32L	TRC-LWM-3-48L	TRC-LWM-4-64L	TRC-LWM-5-80L
1	350mA	18W	36W	52W	68W	85W
2	530mA	28W	54W	79W	103W	128W
3	700mA	37W	71W	104W	136W	169W
4	825mA	43W	84W	-	-	-
5	1050mA	55W	-	-	-	-

Generated by wpDataTables

TRC-LWM-1 Lumens

ORDER	Model	15°	30°	55°	85°	T4FTW
1	TRC-LWM-1-16L-35-27K7	2,102	1,966	1,981	2,026	1,603
2	TRC-LWM-1-16L-35-27K8	1,959	1,832	1,846	1,889	1,494
3	TRC-LWM-1-16L-35-30K7	2,439	2,282	2,299	2,352	1,860
4	TRC-LWM-1-16L-35-30K8	2,114	1,977	1,993	2,038	1,612
5	TRC-LWM-1-16L-35-35K8	2,122	1,984	2,000	2,045	1,618
6	TRC-LWM-1-16L-35-40K7	2,502	2,340	2,358	2,412	1,908
7	TRC-LWM-1-16L-35-40K8	2,252	2,106	2,122	2,171	1,717
8	TRC-LWM-1-16L-35-50K7	2,502	2,340	2,358	2,412	1,908
9	TRC-LWM-1-16L-35-50K8	2,252	2,106	2,122	2,171	1,717
10	TRC-LWM-1-16L-53-27K7	3,034	2,822	2,846	2,916	2,258
11	TRC-LWM-1-16L-53-27K8	2,828	2,631	2,653	2,719	2,105
12	TRC-LWM-1-16L-53-30K7	3,522	3,276	3,303	3,385	2,621
13	TRC-LWM-1-16L-53-30K8	3,052	2,839	2,863	2,934	2,271
14	TRC-LWM-1-16L-53-35K8	3,063	2,849	2,873	2,944	2,279
15	TRC-LWM-1-16L-53-40K7	3,612	3,360	3,388	3,472	2,688
16	TRC-LWM-1-16L-53-40K8	3,251	3,024	3,049	3,125	2,419
17	TRC-LWM-1-16L-53-50K7	3,612	3,360	3,388	3,472	2,688
18	TRC-LWM-1-16L-53-50K8	3,251	3,024	3,049	3,125	2,419
19	TRC-LWM-1-16L-7-27K7	3,699	3,419	3,450	3,543	2,673
20	TRC-LWM-1-16L-7-27K8	3,448	3,187	3,216	3,303	2,492
21	TRC-LWM-1-16L-7-30K7	4,293	3,968	4,004	4,113	3,102
22	TRC-LWM-1-16L-7-30K8	3,721	3,439	3,470	3,564	2,689
23	TRC-LWM-1-16L-7-35K8	3,734	3,451	3,483	3,577	2,698
24	TRC-LWM-1-16L-7-40K7	4,403	4,070	4,107	4,218	3,182
25	TRC-LWM-1-16L-7-40K8	3,963	3,663	3,696	3,796	2,864
26	TRC-LWM-1-16L-7-50K7	4,403	4,070	4,107	4,218	3,182
27	TRC-LWM-1-16L-7-50K8	3,963	3,663	3,696	3,796	2,864
27	TRC-LWM-1-16L-82-27K7	4,262	3,937	3,973	4,082	3,070
27	TRC-LWM-1-16L-82-27K8	3,973	3,670	3,704	3,805	2,862
27	TRC-LWM-1-16L-82-30K7	4,947	4,570	4,612	4,738	3,564
27	TRC-LWM-1-16L-82-30K8	4,288	3,961	3,997	4,106	3,088
27	TRC-LWM-1-16L-82-35K8	4,303	3,975	4,011	4,120	3,099
27	TRC-LWM-1-16L-82-40K7	5,074	4,687	4,730	4,859	3,655
27	TRC-LWM-1-16L-82-40K8	4,567	4,218	4,257	4,373	3,290
27	TRC-LWM-1-16L-82-50K7	5,074	4,687	4,730	4,859	3,655
27	TRC-LWM-1-16L-82-50K8	4,567	4,218	4,257	4,373	3,290
27	TRC-LWM-1-16L-1-27K7	5,412	4,977	5,014	5,184	3,896
27	TRC-LWM-1-16L-1-27K8	5,045	4,639	4,674	4,833	3,632
27	TRC-LWM-1-16L-1-30K7	6,282	5,777	5,820	6,018	4,522
27	TRC-LWM-1-16L-1-30K8	5,444	5,007	5,044	5,215	3,919
27	TRC-LWM-1-16L-1-35K8	5,464	5,024	5,062	5,234	3,933
27	TRC-LWM-1-16L-1-40K7	6,443	5,925	5,969	6,172	4,638
27	TRC-LWM-1-16L-1-40K8	5,799	5,333	5,372	5,555	4,174
27	TRC-LWM-1-16L-1-50K7	6,443	5,925	5,969	6,172	4,638
27	TRC-LWM-1-16L-1-50K8	5,799	5,333	5,372	5,555	4,174

Generated by wpDataTables

TRC-LWM-2 Lumens

ORDER	Model	15°	30°	55°	85°	T4FTW
1	TRC-LWM-2-32L-35-27K7	4,838	4,506	4,491	4,687	3,871
2	TRC-LWM-2-32L-35-27K8	4,510	4,200	4,186	4,369	3,608
3	TRC-LWM-2-32L-35-30K7	5,616	5,230	5,212	5,441	4,493
4	TRC-LWM-2-32L-35-30K8	4,867	4,533	4,517	4,715	3,894
5	TRC-LWM-2-32L-35-35K8	4,884	4,549	4,533	4,732	3,908
6	TRC-LWM-2-32L-35-40K7	5,760	5,364	5,346	5,580	4,608
7	TRC-LWM-2-32L-35-40K8	5,184	4,828	4,811	5,022	4,147
8	TRC-LWM-2-32L-35-50K7	5,760	5,364	5,346	5,580	4,608
9	TRC-LWM-2-32L-35-50K8	5,184	4,828	4,811	5,022	4,147
10	TRC-LWM-2-32L-53-27K7	6,895	6,305	6,290	6,577	5,352
11	TRC-LWM-2-32L-53-27K8	6,427	5,877	5,863	6,131	4,989
12	TRC-LWM-2-32L-53-30K7	8,003	7,318	7,301	7,634	6,213
13	TRC-LWM-2-32L-53-30K8	6,936	6,343	6,327	6,616	5,384
14	TRC-LWM-2-32L-53-35K8	6,960	6,365	6,350	6,640	5,403
15	TRC-LWM-2-32L-53-40K7	8,208	7,506	7,488	7,830	6,372
16	TRC-LWM-2-32L-53-40K8	7,387	6,755	6,739	7,047	5,735
17	TRC-LWM-2-32L-53-50K7	8,208	7,506	7,488	7,830	6,372
18	TRC-LWM-2-32L-53-50K8	7,387	6,755	6,739	7,047	5,735
19	TRC-LWM-2-32L-7-27K7	8,447	7,717	7,702	8,034	6,461
20	TRC-LWM-2-32L-7-27K8	7,874	7,193	7,179	7,489	6,023
21	TRC-LWM-2-32L-7-30K7	9,805	8,957	8,940	9,325	7,500
22	TRC-LWM-2-32L-7-30K8	8,497	7,763	7,748	8,082	6,500
23	TRC-LWM-2-32L-7-35K8	8,527	7,791	7,775	8,110	6,523
24	TRC-LWM-2-32L-7-40K7	10,056	9,187	9,169	9,564	7,692
25	TRC-LWM-2-32L-7-40K8	9,050	8,268	8,252	8,608	6,923
26	TRC-LWM-2-32L-7-50K7	10,056	9,187	9,169	9,564	7,692
27	TRC-LWM-2-32L-7-50K8	9,050	8,268	8,252	8,608	6,923
27	TRC-LWM-2-32L-82-27K7	9,949	9,032	9,017	9,455	7,550
27	TRC-LWM-2-32L-82-27K8	9,274	8,419	8,405	8,813	7,038
27	TRC-LWM-2-32L-82-30K7	11,548	10,483	10,466	10,975	8,763
27	TRC-LWM-2-32L-82-30K8	10,008	9,085	9,070	9,511	7,595
27	TRC-LWM-2-32L-82-35K8	10,044	9,118	9,102	9,545	7,622
27	TRC-LWM-2-32L-82-40K7	11,844	10,752	10,734	11,256	8,988
27	TRC-LWM-2-32L-82-40K8	10,660	9,677	9,661	10,130	8,089
27	TRC-LWM-2-32L-82-50K7	11,844	10,752	10,734	11,256	8,988
27	TRC-LWM-2-32L-82-50K8	10,660	9,677	9,661	10,130	8,089

Generated by wpDataTables

TRC-LWM-3 Lumens

ORDER	Model	15°	30°	55°	85°	T4FTW	LM/W	WATTAGE
1	TRC-LWM-3-48L-35-27K7	6,989	6,639	6,683	6,770	5,591	108	52
2	TRC-LWM-3-48L-35-27K8	6,515	6,189	6,230	6,311	5,212	100	52
3	TRC-LWM-3-48L-35-30K7	8,112	7,706	7,757	7,859	6,490	125	52
4	TRC-LWM-3-48L-35-30K8	7,030	6,679	6,723	6,811	5,624	108	52
5	TRC-LWM-3-48L-35-35K8	7,055	6,703	6,747	6,835	5,644	109	52
6	TRC-LWM-3-48L-35-40K7	8,320	7,904	7,956	8,060	6,656	128	52
7	TRC-LWM-3-48L-35-40K8	7,488	7,114	7,160	7,254	5,990	115	52
8	TRC-LWM-3-48L-35-50K7	8,320	7,904	7,956	8,060	6,656	128	52
9	TRC-LWM-3-48L-35-50K8	7,488	7,114	7,160	7,254	5,990	115	52
10	TRC-LWM-3-48L-53-27K7	10,087	9,423	9,489	9,622	7,830	99	79
11	TRC-LWM-3-48L-53-27K8	9,402	8,784	8,846	8,969	7,299	92	79
12	TRC-LWM-3-48L-53-30K7	11,708	10,938	11,015	11,169	9,089	115	79
13	TRC-LWM-3-48L-53-30K8	10,147	9,479	9,546	9,679	7,877	100	79
14	TRC-LWM-3-48L-53-35K8	10,183	9,513	9,580	9,714	7,905	100	79
15	TRC-LWM-3-48L-53-40K7	12,008	11,218	11,297	11,455	9,322	118	79
16	TRC-LWM-3-48L-53-40K8	10,807	10,096	10,167	10,310	8,390	106	79
17	TRC-LWM-3-48L-53-50K7	12,008	11,218	11,297	11,455	9,322	118	79
18	TRC-LWM-3-48L-53-50K8	10,807	10,096	10,167	10,310	8,390	106	79
19	TRC-LWM-3-48L-7-27K7	12,554	11,678	11,702	11,802	9,416	91	104
20	TRC-LWM-3-48L-7-27K8	11,702	10,885	10,908	11,001	8,777	84	104
21	TRC-LWM-3-48L-7-30K7	14,571	13,554	13,583	13,699	10,930	105	104
22	TRC-LWM-3-48L-7-30K8	12,629	11,747	11,772	11,872	9,472	91	104
23	TRC-LWM-3-48L-7-35K8	12,673	11,789	11,813	11,914	9,506	91	104
24	TRC-LWM-3-48L-7-40K7	14,945	13,902	13,931	14,050	11,210	108	104
25	TRC-LWM-3-48L-7-40K8	13,451	12,512	12,538	12,645	10,089	97	104
26	TRC-LWM-3-48L-7-50K7	14,945	13,902	13,931	14,050	11,210	108	104
27	TRC-LWM-3-48L-7-50K8	13,451	12,512	12,538	12,645	10,089	97	104

Generated by wpDataTables

TRC-LWM-4 Lumens

ORDER	Model	15°	15° LM/W	30°	30° LM/W	55°	55° LM/W	85°	85° LM/W	T2	T2 LM/W	T3	T3 LM/W	T4FTW	LM/W	WATTAGE
1	TRC-LWM-4-64L-35-27K7	9,139	134	8,511	125	8,568	126	8,593	126	7,940	117	7,768	114	7,026	103	68
2	TRC-LWM-4-64L-35-27K8	8,519	125	7,933	117	7,987	117	8,010	118	7,401	109	7,241	106	6,549	96	68
3	TRC-LWM-4-64L-35-30K7	10,608	156	9,879	145	9,945	146	9,974	147	9,216	136	9,017	133	8,155	120	68
4	TRC-LWM-4-64L-35-30K8	9,194	135	8,562	126	8,619	127	8,644	127	7,987	117	7,815	115	7,068	104	68
5	TRC-LWM-4-64L-35-35K8	9,226	136	8,592	126	8,650	127	8,675	128	8,015	118	7,842	115	7,093	104	68
6	TRC-LWM-4-64L-35-40K7	10,880	160	10,132	149	10,200	150	10,230	150	9,452	139	9,248	136	8,364	123	68
7	TRC-LWM-4-64L-35-40K8	9,792	144	9,119	134	9,180	135	9,207	135	8,507	125	8,323	122	7,528	111	68
8	TRC-LWM-4-64L-35-50K7	10,880	160	10,132	149	10,200	150	10,230	150	9,452	139	9,248	136	8,364	123	68
9	TRC-LWM-4-64L-35-50K8	9,792	144	9,119	134	9,180	135	9,207	135	8,507	125	8,323	122	7,528	111	68
10	TRC-LWM-4-64L-53-27K7	12,978	126	12,026	117	12,113	118	12,142	118	11,161	108	10,902	106	9,777	95	103
11	TRC-LWM-4-64L-53-27K8	12,097	117	11,210	109	11,291	110	11,318	110	10,404	101	10,162	99	9,113	88	103
12	TRC-LWM-4-64L-53-30K7	15,064	146	13,959	136	14,060	137	14,094	137	12,955	126	12,654	123	11,348	110	103
13	TRC-LWM-4-64L-53-30K8	13,055	127	12,098	117	12,185	118	12,214	119	11,228	109	10,966	106	9,835	95	103
14	TRC-LWM-4-64L-53-35K8	13,102	127	12,141	118	12,228	119	12,258	119	11,267	109	11,005	107	9,870	96	103
15	TRC-LWM-4-64L-53-40K7	15,450	150	14,317	139	14,420	140	14,455	140	13,287	129	12,978	126	11,639	113	103
16	TRC-LWM-4-64L-53-40K8	13,905	135	12,885	125	12,978	126	13,010	126	11,958	116	11,680	113	10,475	102	103
17	TRC-LWM-4-64L-53-50K7	15,450	150	14,317	139	14,420	140	14,455	140	13,287	129	12,978	126	11,639	113	103
18	TRC-LWM-4-64L-53-50K8	13,905	135	12,885	125	12,978	126	13,010	126	11,958	116	11,680	113	10,475	102	103
19	TRC-LWM-4-64L-7-27K7	16,115	118	14,787	109	14,900	110	14,907	110	13,591	100	13,198	97	11,747	86	136
20	TRC-LWM-4-64L-7-27K8	15,021	110	13,783	101	13,889	102	13,895	102	12,669	93	12,302	90	10,950	81	136
21	TRC-LWM-4-64L-7-30K7	18,704	138	17,163	126	17,295	127	17,302	127	15,776	116	15,319	113	13,635	100	136
22	TRC-LWM-4-64L-7-30K8	16,210	119	14,875	109	14,989	110	14,995	110	13,672	101	13,277	98	11,817	87	136
23	TRC-LWM-4-64L-7-35K8	16,268	120	14,927	110	15,042	111	15,049	111	13,721	101	13,324	98	11,859	87	136
24	TRC-LWM-4-64L-7-40K7	19,184	141	17,603	129	17,738	130	17,746	130	16,180	119	15,712	116	13,985	103	136
25	TRC-LWM-4-64L-7-40K8	17,266	127	15,843	116	15,964	117	15,971	117	14,562	107	14,141	104	12,587	93	136
26	TRC-LWM-4-64L-7-50K7	19,184	141	17,603	129	17,738	130	17,746	130	16,180	119	15,712	116	13,985	103	136
27	TRC-LWM-4-64L-7-50K8	17,266	127	15,843	116	15,964	117	15,971	117	14,562	107	14,141	104	12,587	93	136

Generated by wpDataTables

TRC-LWM-5 Lumens

ORDER	Model	15°	15° LM/W	30°	30° LM/W	55°	55° LM/W	85°	85° LM/W	T2	T2 LM/W	T3	T3 LM/W	T4FTW	LM/W	WATTAGE
1	TRC-LWM-5-80L-35-27K7	11,495	135	10,781	127	11,067	130	11,101	131	10,282	121	10,424	123	9,282	109	85
2	TRC-LWM-5-80L-35-27K8	10,715	126	10,050	118	10,316	121	10,347	122	9,584	113	9,717	114	8,652	102	85
3	TRC-LWM-5-80L-35-30K7	13,343	157	12,514	147	12,846	151	12,885	152	11,934	140	12,100	142	10,774	127	85
4	TRC-LWM-5-80L-35-30K8	11,564	136	10,846	128	11,133	131	11,167	131	10,343	122	10,486	123	9,337	110	85
5	TRC-LWM-5-80L-35-35K8	11,605	137	10,884	128	11,172	131	11,206	132	10,380	122	10,524	124	9,370	110	85
6	TRC-LWM-5-80L-35-40K7	13,685	161	12,835	151	13,175	155	13,215	155	12,240	144	12,410	146	11,050	130	85
7	TRC-LWM-5-80L-35-40K8	12,317	145	11,552	136	11,858	140	11,894	140	11,016	130	11,169	131	9,945	117	85
8	TRC-LWM-5-80L-35-50K7	13,685	161	12,835	151	13,175	155	13,215	155	12,240	144	12,410	146	11,050	130	85
9	TRC-LWM-5-80L-35-50K8	12,317	145	11,552	136	11,858	140	11,894	140	11,016	130	11,169	131	9,945	117	85
10	TRC-LWM-5-80L-53-27K7	16,666	130	15,160	118	15,590	122	15,641	122	14,408	113	14,623	114	12,902	101	128
11	TRC-LWM-5-80L-53-27K8	15,535	121	14,132	110	14,532	114	14,579	114	13,430	105	13,630	106	12,027	94	128
12	TRC-LWM-5-80L-53-30K7	19,344	151	17,597	137	18,096	141	18,155	142	16,723	131	16,973	133	14,976	117	128
13	TRC-LWM-5-80L-53-30K8	16,765	131	15,251	119	15,683	123	15,734	123	14,493	113	14,710	115	12,979	101	128
14	TRC-LWM-5-80L-53-35K8	16,824	131	15,305	120	15,739	123	15,790	123	14,545	114	14,762	115	13,025	102	128
15	TRC-LWM-5-80L-53-40K7	19,840	155	18,048	141	18,560	145	18,620	145	17,152	134	17,408	136	15,360	120	128
16	TRC-LWM-5-80L-53-40K8	17,856	140	16,243	127	16,704	131	16,758	131	15,437	121	15,667	122	13,824	108	128
17	TRC-LWM-5-80L-53-50K7	19,840	155	18,048	141	18,560	145	18,620	145	17,152	134	17,408	136	15,360	120	128
18	TRC-LWM-5-80L-53-50K8	17,856	140	16,243	127	16,704	131	16,758	131	15,437	121	15,667	122	13,824	108	128
19	TRC-LWM-5-80L-7-27K7	20,611	122	18,530	110	19,128	113	19,216	114	17,667	105	17,889	106	15,626	92	169
20	TRC-LWM-5-80L-7-27K8	19,212	114	17,273	102	17,830	106	17,912	106	16,468	97	16,675	99	14,565	86	169
21	TRC-LWM-5-80L-7-30K7	23,924	142	21,509	127	22,202	131	22,304	132	20,506	121	20,764	123	18,137	107	169
22	TRC-LWM-5-80L-7-30K8	20,734	123	18,641	110	19,241	114	19,330	114	17,772	105	17,995	106	15,719	93	169
23	TRC-LWM-5-80L-7-35K8	20,807	123	18,707	111	19,310	114	19,399	115	17,835	106	18,059	107	15,774	93	169
24	TRC-LWM-5-80L-7-40K7	24,537	145	22,060	131	22,771	135	22,876	135	21,032	124	21,296	126	18,602	110	169
25	TRC-LWM-5-80L-7-40K8	22,083	131	19,854	117	20,494	121	20,588	122	18,929	112	19,166	113	16,742	99	169
26	TRC-LWM-5-80L-7-50K7	24,537	145	22,060	131	22,771	135	22,876	135	21,032	124	21,296	126	18,602	110	169
27	TRC-LWM-5-80L-7-50K8	22,083	131	19,854	117	20,494	121	20,588	122	18,929	112	19,166	113	16,742	99	169

Generated by wpDataTables

Download WHY SILICONE OPTICS? Brochure to Learn more!

Form
• Elegant Rectilinear Extruded Aluminum Housing
• Corrosion Resistant Stainless Steel External Hardware
• Sleek, Low Profile Housing
• Spec Grade Performance
• Engineered For Optimum Thermal Management
• 10 Architectural Finishes Standard, RAL Colors Available

Function
• Micro Optics IES Distributions 15°, 30°,55°, 85°, T2, T3, T4FTW, T5W
• 0-10V Dimming Drivers THD @ Max Load < 15% Power factor @ Max Load < 0.95
• Amber, 2700K, 3000K, 3500K, 4000K, or 5000K
• 16L, 32L, 48L, or 64L LED
• 21-205 Watts
• CRI 70, 80, or 90
• Extruded Aluminum Heat Sink
• 5 Mils Powder Coat
• Aluminum Pole .250 Wall
• Standard with Clear Lens

Reliability
• Silicone Micro Optics
• 5 Year Standard Warranty
• IP67 Optics
• Reduces Energy Consumption And Costs Up To 65%
