HORIZON MA

Slider
  • Related marketing material is available for download or by request for delivery.  Standard shipping is 5-7 business days via UPS Ground. For expedited delivery, please contact factory. Click HERE to order literature.



    Click on image to download!





  • Horizon BUG Ratings

    Order Model T2 BUG T3 BUG T3 HSS BUG T4 BUG T4 HSS BUG T5 BUG WATTS
    1.00 HRZ-1-16L-35-30K B1-U0-G1 B1-U0-G1 B0-U0-G0 B1-U0-G1 B0-U0-G0 B2-U0-G1 18.00
    2.00 HRZ-1-16L-35-40K B1-U0-G1 B1-U0-G1 B0-U0-G0 B1-U0-G1 B0-U0-G0 B2-U0-G1 18.00
    3.00 HRZ-1-16L-35-50K B1-U0-G1 B1-U0-G1 B0-U0-G0 B1-U0-G1 B0-U0-G0 B2-U0-G1 18.00
    4.00 HRZ-1-16L-53-30K B1-U0-G1 B1-U0-G1 B0-U0-G1 B1-U0-G1 B0-U0-G1 B2-U0-G1 28.00
    5.00 HRZ-1-16L-53-40K B1-U0-G1 B1-U0-G1 B0-U0-G1 B1-U0-G1 B0-U0-G1 B2-U0-G1 28.00
    6.00 HRZ-1-16L-53-50K B1-U0-G1 B1-U0-G1 B0-U0-G1 B1-U0-G1 B0-U0-G1 B2-U0-G1 28.00
    7.00 HRZ-1-16L-7-30K B1-U0-G1 B1-U0-G1 B0-U0-G1 B1-U0-G1 B0-U0-G1 B3-U0-G1 36.00
    8.00 HRZ-1-16L-7-40K B1-U0-G1 B1-U0-G1 B0-U0-G1 B1-U0-G1 B0-U0-G1 B3-U0-G1 36.00
    9.00 HRZ-1-16L-7-50K B1-U0-G1 B1-U0-G1 B0-U0-G1 B1-U0-G1 B0-U0-G1 B3-U0-G1 36.00
    10.00 HRZ-1-16L-1-30K B1-U0-G1 B1-U0-G1 B0-U0-G1 B1-U0-G2 B0-U0-G1 B3-U0-G1 56.00
    11.00 HRZ-1-16L-1-40K B1-U0-G1 B1-U0-G1 B0-U0-G1 B1-U0-G2 B0-U0-G1 B3-U0-G1 56.00
    12.00 HRZ-1-16L-1-50K B1-U0-G1 B1-U0-G2 B0-U0-G1 B1-U0-G2 B0-U0-G1 B3-U0-G1 56.00
    13.00 HRZ-1-32L-53-30K B1-U0-G1 B1-U0-G1 B0-U0-G1 B1-U0-G2 B0-U0-G1 B3-U0-G1 56.00
    14.00 HRZ-1-32L-53-40K B1-U0-G1 B1-U0-G1 B0-U0-G1 B1-U0-G2 B0-U0-G1 B3-U0-G1 56.00
    15.00 HRZ-1-32L-53-50K B1-U0-G1 B1-U0-G2 B0-U0-G1 B1-U0-G2 B0-U0-G1 B3-U0-G1 56.00
    16.00 HRZ-1-32L-7-30K B2-U0-G2 B2-U0-G2 B0-U0-G1 B2-U0-G2 B0-U0-G1 B3-U0-G2 71.00
    17.00 HRZ-1-32L-7-40K B2-U0-G2 B2-U0-G2 B0-U0-G1 B2-U0-G2 B0-U0-G2 B3-U0-G2 71.00
    18.00 HRZ-1-32L-7-50K B2-U0-G2 B2-U0-G2 B0-U0-G1 B2-U0-G2 B0-U0-G2 B3-U0-G2 71.00
    19.00 HRZ-1-32L-1-30K B2-U0-G2 B2-U0-G2 B0-U0-G2 B2-U0-G2 B0-U0-G2 B4-U0-G2 106.00
    20.00 HRZ-1-32L-1-40K B2-U0-G2 B2-U0-G2 B0-U0-G2 B2-U0-G2 B0-U0-G2 B4-U0-G2 106.00
    21.00 HRZ-1-32L-1-50K B2-U0-G2 B2-U0-G2 B0-U0-G2 B2-U0-G2 B0-U0-G2 B4-U0-G2 106.00
    22.00 HRZ-1-48L-7-30K B2-U0-G2 B2-U0-G2 B0-U0-G2 B2-U0-G2 B0-U0-G2 B4-U0-G2 104.00
    23.00 HRZ-1-48L-7-40K B2-U0-G2 B2-U0-G2 B0-U0-G2 B2-U0-G2 B0-U0-G2 B4-U0-G2 104.00
    24.00 HRZ-1-48L-7-50K B2-U0-G2 B2-U0-G2 B0-U0-G2 B2-U0-G2 B0-U0-G2 B4-U0-G2 104.00
    25.00 HRZ-1-48L-1-30K B3-U0-G3 B3-U0-G3 B0-U0-G2 B3-U0-G3 B1-U0-G2 B4-U0-G2 156.00
    26.00 HRZ-1-48L-1-40K B3-U0-G3 B3-U0-G3 B0-U0-G2 B3-U0-G3 B1-U0-G2 B4-U0-G2 156.00
    27.00 HRZ-1-48L-1-50K B3-U0-G3 B3-U0-G3 B1-U0-G2 B3-U0-G3 B1-U0-G2 B4-U0-G2 156.00
    28.00 HRZ-1-64L-7-30K B3-U0-G3 B2-U0-G2 B0-U0-G2 B3-U0-G3 B0-U0-G2 B4-U0-G2 136.00
    29.00 HRZ-1-64L-7-40K B3-U0-G3 B2-U0-G2 B0-U0-G2 B3-U0-G3 B0-U0-G2 B4-U0-G2 136.00
    30.00 HRZ-1-64L-7-50K B3-U0-G3 B2-U0-G2 B0-U0-G2 B3-U0-G3 B1-U0-G2 B4-U0-G2 136.00
    Generated by wpDataTables
  • Horizon Wattage

    Milliamps 16L 32L 48L 64L
    350 mA (35) 18w - - -
    530 mA (53) 28w 56w - -
    700 mA (7) 36w 71w 104w 136w
    1050 mA (1) 56w 106w 156w 205w
    Generated by wpDataTables



    Horizon Lumens

    Order Model T2 Lumens T2 Lm/W T3 Lumens T3 Lm/W T3-HSS Lumens T3-HSS Lm/W T4 Lumens T4 Lm/W T4-HSS Lumens T4-HSS Lm/W T5 Lumens T5 Lm/W WATTS
    1.00 HRZ-1-16L-35-30K 2142 119 2088 116 1044 58 2070 115 1026 57 2160 120 18
    2.00 HRZ-1-16L-35-40K 2305 128 2247 125 1116 62 2227 124 1098 61 2322 129 18
    3.00 HRZ-1-16L-35-50K 2356 131 2297 128 1188 66 2277 127 1170 65 2376 132 18
    4.00 HRZ-1-16L-53-30K 3275 117 3192 114 1624 58 3165 113 1596 57 3304 118 28
    5.00 HRZ-1-16L-53-40K 3524 126 3435 123 1736 62 3406 122 1708 61 3556 127 28
    6.00 HRZ-1-16L-53-50K 3603 129 3511 125 1848 66 3482 124 1820 65 3640 130 28
    7.00 HRZ-1-16L-7-30K 4100 114 4115 111 2088 58 4003 111 2052 57 4176 116 36
    8.00 HRZ-1-16L-7-40K 4411 123 4300 119 2232 62 4308 120 2196 61 4500 125 36
    9.00 HRZ-1-16L-7-50K 4510 125 4396 122 2376 66 4404 122 2340 65 4608 128 36
    10.00 HRZ-1-16L-1-30K 5858 105 5712 102 3248 58 5661 101 3192 57 5880 105 56
    11.00 HRZ-1-16L-1-40K 6303 113 6146 110 3472 62 6091 109 3416 61 6328 113 56
    12.00 HRZ-1-16L-1-50K 6443 115 6283 112 3696 66 6227 111 3640 65 6496 116 56
    13.00 HRZ-1-32L-53-30K 5858 105 5712 102 3248 58 5661 101 3192 57 5880 105 56
    14.00 HRZ-1-32L-53-40K 6303 113 6146 110 3472 62 6091 109 3416 61 6328 113 56
    15.00 HRZ-1-32L-53-50K 6443 115 6283 112 3696 66 6227 111 3640 65 6496 116 56
    16.00 HRZ-1-32L-7-30K 7427 105 7881 111 4118 58 7896 111 4047 57 8236 116 71
    17.00 HRZ-1-32L-7-40K 7991 113 8480 119 4402 62 8496 120 4331 61 8875 125 71
    18.00 HRZ-1-32L-7-50K 8169 115 8669 122 4686 66 8685 122 4615 65 9088 128 71
    19.00 HRZ-1-32L-1-30K 11088 105 10812 102 6148 58 10715 101 6042 57 11130 105 106
    20.00 HRZ-1-32L-1-40K 11930 113 11634 110 6572 62 11529 109 6466 61 11978 113 106
    21.00 VSR-1-32L-1-50K 12196 115 11893 112 6996 66 11787 111 6890 65 12296 116 106
    22.00 HRZ-1-48L-7-30K 11844 114 11544 111 6032 58 11648 112 5928 57 12068 116 104
    23.00 HRZ-1-48L-7-40K 12744 123 12421 119 6448 62 12444 120 6344 61 12985 125 104
    24.00 HRZ-1-48L-7-50K 13028 125 12698 122 6864 66 12792 123 6760 65 13275 128 104
    25.00 HRZ-1-48L-1-30K 16318 105 15912 102 9048 58 15769 101 8892 57 16455 105 156
    26.00 HRZ-1-48L-1-40K 17558 113 17121 110 9672 62 16968 109 9516 61 17705 113 156
    27.00 HRZ-1-48L-1-50K 17950 115 17503 112 10296 66 17346 111 10140 65 18100 116 156
    28.00 HRZ-1-64L-7-30K 15488 114 15096 111 7888 58 15124 111 7752 57 15781 116 136
    29.00 HRZ-1-64L-7-40K 16665 123 16243 119 8432 62 16273 120 8296 61 16981 125 136
    30.00 HRZ-1-64L-7-50K 17037 125 16606 122 8976 66 16728 123 8840 65 17359 128 136
    31.00 HRZ-1-64L-1-30K 23346 114 22755 111 11890 58 20722 101 11685 57 23780 116 205
    32.00 HRZ-1-64L-1-40K 25120 123 24484 119 12710 62 22297 109 12505 61 25625 125 205
    33.00 HRZ-1-64L-1-50K 25681 125 25030 122 13530 66 22795 111 13325 65 26240 128 205
    Generated by wpDataTables













  • – Designed to blend beautifully on residential, commercial or recreational applications
    – Neighborhood friendly full Cutoff Dark Sky luminaire design with recessed LEDs to eliminate direct glare
    – Clear tempered safety glass lens with silicone gasket that improves fixture reliability
    – Available from 18 to 205 watts
    – Throws light up to five mounting heights in all directions, enabling performance to exceed IES minimum foot candle levels and extend maintenance cycles
    – Kelvin temperature offering of (warm) 3000, (neutral) 4000 and (cool) 5000 in Type 2, 3, 4 and 5 light distributions
    – Philips Advance driver technology warranted 5 years
    – Conforms to the strictest Made in America standards designed, tooled, fabricated and assembled in the USA
