BRITELINE Wattage

Sl. No	Catalog Number	LED Count	Wattage	Max Efficacy
1	BRITELINE GEN3 - SIZE 1	234	630W ( 66800 - 95800 Lumens)	152
2	BRITELINE GEN3 - SIZE 1	351	620W (53200 - 110,400 Lumens)	178
3	BRITELINE GEN3 - SIZE 2	468	1250W (133,800 - 191,900 Lumens)	154
4	BRITELINE GEN3 - SIZE 2	702	1220W (106,100 - 220,200 Lumens)	180
5	BRITELINE GEN3 - SIZE 3	702	1860W (200,400 - 287,500 Lumens)	155
6	BRITELINE GEN3 - SIZE 3	1,053	1830W (159,200 - 330,300 Lumens)	180

Generated by wpDataTables

Briteline Gen 3 Size 1 Lumens

Sl.No	Model	Wattage	Color Temp / CRI	Lumens Min	Lumens Max	Lm/W
1	BRITEL31-234L-5468-SY8	630	730	86,400.00	88,300.00	140
2	BRITEL31-234L-5468-SY8	630	740	93,800.00	95,800.00	152
3	BRITEL31-234L-5468-SY8	630	757	74,100.00	75,700.00	120
4	BRITEL31-234L-5468-SY8	630	830	80,900.00	82,700.00	131
5	BRITEL31-234L-5468-SY8	630	840	86,400.00	88,300.00	140
6	BRITEL31-234L-5468-SY8	630	857	86,400.00	88,300.00	140
7	BRITEL31-234L-5468-SY8	630	940	66,800.00	68,200.00	108
8	BRITEL31-234L-5468-SY8	630	957	74,100.00	75,700.00	120
9	BRITEL31-351L-5469-ASY30	620	730	68,800.00	101,700.00	164
10	BRITEL31-351L-5469-ASY30	620	740	74,700.00	110,400.00	178
11	BRITEL31-351L-5469-ASY30	620	757	72,500.00	107,100.00	173
12	BRITEL31-351L-5469-ASY30	620	830	64,500.00	95,300.00	154
13	BRITEL31-351L-5469-ASY30	620	840	68,800.00	101,700.00	164
14	BRITEL31-351L-5469-ASY30	620	857	68,800.00	101,700.00	164
15	BRITEL31-351L-5469-ASY30	620	940	53,200.00	78,600.00	127
16	BRITEL31-351L-5469-ASY30	620	957	59,000.00	87,200.00	141
17	BRITEL31-351L-5470-ASY35	620	730	68,800.00	101,700.00	164
18	BRITEL31-351L-5470-ASY35	620	740	74,700.00	110,400.00	178
19	BRITEL31-351L-5470-ASY35	620	757	72,500.00	107,100.00	173
20	BRITEL31-351L-5470-ASY35	620	830	64,500.00	95,300.00	154
21	BRITEL31-351L-5470-ASY35	620	840	68,800.00	101,700.00	164
22	BRITEL31-351L-5470-ASY35	620	857	68,800.00	101,700.00	164
23	BRITEL31-351L-5470-ASY35	620	940	53,200.00	78,600.00	127
24	BRITEL31-351L-5470-ASY35	620	957	59,000.00	87,200.00	141
25	BRITEL31-351L-5472-ASY55NB	620	730	68,800.00	101,700.00	164
26	BRITEL31-351L-5472-ASY55NB	620	740	74,700.00	110,400.00	178
27	BRITEL31-351L-5472-ASY55NB	620	757	72,500.00	107,100.00	173
28	BRITEL31-351L-5472-ASY55NB	620	830	64,500.00	95,300.00	154
29	BRITEL31-351L-5472-ASY55NB	620	840	68,800.00	101,700.00	164
30	BRITEL31-351L-5472-ASY55NB	620	857	68,800.00	101,700.00	164
31	BRITEL31-351L-5472-ASY55NB	620	940	53,200.00	78,600.00	127
32	BRITEL31-351L-5472-ASY55NB	620	957	59,000.00	87,200.00	141
33	BRITEL31-351L-5473-ASY55MB	620	730	68,800.00	101,700.00	164
34	BRITEL31-351L-5473-ASY55MB	620	740	74,700.00	110,400.00	178
35	BRITEL31-351L-5473-ASY55MB	620	757	72,500.00	107,100.00	173
36	BRITEL31-351L-5473-ASY55MB	620	830	64,500.00	95,300.00	154
37	BRITEL31-351L-5473-ASY55MB	620	840	68,800.00	101,700.00	164
38	BRITEL31-351L-5473-ASY55MB	620	857	68,800.00	101,700.00	164
39	BRITEL31-351L-5473-ASY55MB	620	940	53,200.00	78,600.00	127
40	BRITEL31-351L-5473-ASY55MB	620	957	59,000.00	87,200.00	141
41	BRITEL31-351L-7218-SY15	620	730	68,800.00	101,700.00	164
42	BRITEL31-351L-7218-SY15	620	740	74,700.00	110,400.00	178
43	BRITEL31-351L-7218-SY15	620	757	72,500.00	107,100.00	173
44	BRITEL31-351L-7218-SY15	620	830	64,500.00	95,300.00	154
45	BRITEL31-351L-7218-SY15	620	840	68,800.00	101,700.00	164
46	BRITEL31-351L-7218-SY15	620	857	68,800.00	101,700.00	164
47	BRITEL31-351L-7218-SY15	620	940	53,200.00	78,600.00	127
48	BRITEL31-351L-7218-SY15	620	957	59,000.00	87,200.00	141
49	BRITEL31-351L-7219-SY30	620	730	68,800.00	101,700.00	164
50	BRITEL31-351L-7219-SY30	620	740	74,700.00	110,400.00	178
51	BRITEL31-351L-7219-SY30	620	757	72,500.00	107,100.00	173
52	BRITEL31-351L-7219-SY30	620	830	64,500.00	95,300.00	154
53	BRITEL31-351L-7219-SY30	620	840	68,800.00	101,700.00	164
54	BRITEL31-351L-7219-SY30	620	857	68,800.00	101,700.00	164
55	BRITEL31-351L-7219-SY30	620	940	53,200.00	78,600.00	127
56	BRITEL31-351L-7219-SY30	620	957	59,000.00	87,200.00	141

Generated by wpDataTables

Briteline Gen 3 Size 2 Lumens

Sl.No	Model	Wattage	Color Temp / CRI	Lumens Min	Lumens Max	Lm/W
57	BRITEL32-468L-5468-SY8	1,250.00	730	173,200.00	176,900.00	142
58	BRITEL32-468L-5468-SY8	1,250.00	740	187,800.00	191,900.00	154
59	BRITEL32-468L-5468-SY8	1,250.00	757	182,300.00	186,300.00	149
60	BRITEL32-468L-5468-SY8	1,250.00	830	162,200.00	165,700.00	133
61	BRITEL32-468L-5468-SY8	1,250.00	840	173,200.00	176,900.00	142
62	BRITEL32-468L-5468-SY8	1,250.00	857	173,200.00	176,900.00	142
63	BRITEL32-468L-5468-SY8	1,250.00	940	133,800.00	136,700.00	109
64	BRITEL32-468L-5468-SY8	1,250.00	957	148,400.00	151,700.00	121
65	BRITEL32-702L-5469-ASY30	1,220.00	730	137,400.00	203,000.00	166
66	BRITEL32-702L-5469-ASY30	1,220.00	740	149,000.00	220,200.00	180
67	BRITEL32-702L-5469-ASY30	1,220.00	757	144,600.00	213,800.00	175
68	BRITEL32-702L-5469-ASY30	1,220.00	830	128,600.00	190,100.00	156
69	BRITEL32-702L-5469-ASY30	1,220.00	840	137,400.00	203,000.00	166
70	BRITEL32-702L-5469-ASY30	1,220.00	857	137,400.00	203,000.00	166
71	BRITEL32-702L-5469-ASY30	1,220.00	940	106,100.00	156,800.00	129
72	BRITEL32-702L-5469-ASY30	1,220.00	957	117,700.00	174,000.00	143
73	BRITEL32-702L-5470-ASY35	1,220.00	730	137,400.00	203,000.00	166
74	BRITEL32-702L-5470-ASY35	1,220.00	740	149,000.00	220,200.00	180
75	BRITEL32-702L-5470-ASY35	1,220.00	757	144,600.00	213,800.00	175
76	BRITEL32-702L-5470-ASY35	1,220.00	830	128,600.00	190,100.00	156
77	BRITEL32-702L-5470-ASY35	1,220.00	840	137,400.00	203,000.00	166
78	BRITEL32-702L-5470-ASY35	1,220.00	857	137,400.00	203,000.00	166
79	BRITEL32-702L-5470-ASY35	1,220.00	940	106,100.00	156,800.00	129
80	BRITEL32-702L-5470-ASY35	1,220.00	957	117,700.00	174,000.00	143
81	BRITEL32-702L-5472-ASY55NB	1,220.00	730	137,400.00	203,000.00	166
82	BRITEL32-702L-5472-ASY55NB	1,220.00	740	149,000.00	220,200.00	180
83	BRITEL32-702L-5472-ASY55NB	1,220.00	757	144,600.00	213,800.00	175
84	BRITEL32-702L-5472-ASY55NB	1,220.00	830	128,600.00	190,100.00	156
85	BRITEL32-702L-5472-ASY55NB	1,220.00	840	137,400.00	203,000.00	166
86	BRITEL32-702L-5472-ASY55NB	1,220.00	857	137,400.00	203,000.00	166
87	BRITEL32-702L-5472-ASY55NB	1,220.00	940	106,100.00	156,800.00	129
88	BRITEL32-702L-5472-ASY55NB	1,220.00	957	117,700.00	174,000.00	143
89	BRITEL32-702L-5473-ASY55MB	1,220.00	730	137,400.00	203,000.00	166
90	BRITEL32-702L-5473-ASY55MB	1,220.00	740	149,000.00	220,200.00	180
91	BRITEL32-702L-5473-ASY55MB	1,220.00	757	144,600.00	213,800.00	175
92	BRITEL32-702L-5473-ASY55MB	1,220.00	830	128,600.00	190,100.00	156
93	BRITEL32-702L-5473-ASY55MB	1,220.00	840	137,400.00	203,000.00	166
94	BRITEL32-702L-5473-ASY55MB	1,220.00	857	137,400.00	203,000.00	166
95	BRITEL32-702L-5473-ASY55MB	1,220.00	940	106,100.00	156,800.00	129
96	BRITEL32-702L-5473-ASY55MB	1,220.00	957	117,700.00	174,000.00	143
97	BRITEL32-702L-7218-SY15	1,220.00	730	137,400.00	203,000.00	166
98	BRITEL32-702L-7218-SY15	1,220.00	740	149,000.00	220,200.00	180
99	BRITEL32-702L-7218-SY15	1,220.00	757	144,600.00	213,800.00	175
100	BRITEL32-702L-7218-SY15	1,220.00	830	128,600.00	190,100.00	156
101	BRITEL32-702L-7218-SY15	1,220.00	840	137,400.00	203,000.00	166
102	BRITEL32-702L-7218-SY15	1,220.00	857	137,400.00	203,000.00	166
103	BRITEL32-702L-7218-SY15	1,220.00	940	106,100.00	156,800.00	129
104	BRITEL32-702L-7218-SY15	1,220.00	957	117,700.00	174,000.00	143
105	BRITEL32-702L-7219-SY30	1,220.00	730	137,400.00	203,000.00	166
106	BRITEL32-702L-7219-SY30	1,220.00	740	149,000.00	220,200.00	180
107	BRITEL32-702L-7219-SY30	1,220.00	757	144,600.00	213,800.00	175
108	BRITEL32-702L-7219-SY30	1,220.00	830	128,600.00	190,100.00	156
109	BRITEL32-702L-7219-SY30	1,220.00	840	137,400.00	203,000.00	166
110	BRITEL32-702L-7219-SY30	1,220.00	857	137,400.00	203,000.00	166
111	BRITEL32-702L-7219-SY30	1,220.00	940	106,100.00	156,800.00	129
112	BRITEL32-702L-7219-SY30	1,220.00	957	117,700.00	174,000.00	143

Generated by wpDataTables

BRITELINE GEN3 Size 3 Lumens

Sl.No	Model	Wattage	Color Temp / CRI	Lumens Min	Lumens Max	Lm/W
113	BRITEL33-702L-5468-SY8	1,860.00	730	259,400.00	265,100.00	143
114	BRITEL33-702L-5468-SY8	1,860.00	740	281,400.00	287,500.00	155
115	BRITEL33-702L-5468-SY8	1,860.00	757	273,200.00	279,100.00	150
116	BRITEL33-702L-5468-SY8	1,860.00	830	242,900.00	248,200.00	133
117	BRITEL33-702L-5468-SY8	1,860.00	840	259,400.00	265,100.00	143
118	BRITEL33-702L-5468-SY8	1,860.00	857	259,400.00	265,100.00	143
119	BRITEL33-702L-5468-SY8	1,860.00	940	200,400.00	204,800.00	110
120	BRITEL33-702L-5468-SY8	1,860.00	957	222,400.00	227,200.00	122
121	BRITEL33-1053L-5469-ASY30	1,830.00	730	206,100.00	304,500.00	166
122	BRITEL33-1053L-5469-ASY30	1,830.00	740	223,500.00	330,300.00	180
123	BRITEL33-1053L-5469-ASY30	1,830.00	757	217,000.00	320,700.00	175
124	BRITEL33-1053L-5469-ASY30	1,830.00	830	193,000.00	285,200.00	156
125	BRITEL33-1053L-5469-ASY30	1,830.00	840	206,100.00	304,500.00	166
126	BRITEL33-1053L-5469-ASY30	1,830.00	857	206,100.00	304,500.00	166
127	BRITEL33-1053L-5469-ASY30	1,830.00	940	159,200.00	235,200.00	129
128	BRITEL33-1053L-5469-ASY30	1,830.00	957	176,600.00	261,000.00	143
129	BRITEL33-1053L-5470-ASY35	1,830.00	730	206,100.00	304,500.00	166
130	BRITEL33-1053L-5470-ASY35	1,830.00	740	223,500.00	330,300.00	180
131	BRITEL33-1053L-5470-ASY35	1,830.00	757	217,000.00	320,700.00	175
132	BRITEL33-1053L-5470-ASY35	1,830.00	830	193,000.00	285,200.00	156
133	BRITEL33-1053L-5470-ASY35	1,830.00	840	206,100.00	304,500.00	166
134	BRITEL33-1053L-5470-ASY35	1,830.00	857	206,100.00	304,500.00	166
135	BRITEL33-1053L-5470-ASY35	1,830.00	940	159,200.00	235,200.00	129
136	BRITEL33-1053L-5470-ASY35	1,830.00	957	176,600.00	261,000.00	143
137	BRITEL33-1053L-5472-ASY55NB	1,830.00	730	206,100.00	304,500.00	166
138	BRITEL33-1053L-5472-ASY55NB	1,830.00	740	223,500.00	330,300.00	180
139	BRITEL33-1053L-5472-ASY55NB	1,830.00	757	217,000.00	320,700.00	175
140	BRITEL33-1053L-5472-ASY55NB	1,830.00	830	193,000.00	285,200.00	156
141	BRITEL33-1053L-5472-ASY55NB	1,830.00	840	206,100.00	304,500.00	166
142	BRITEL33-1053L-5472-ASY55NB	1,830.00	857	206,100.00	304,500.00	166
143	BRITEL33-1053L-5472-ASY55NB	1,830.00	940	159,200.00	235,200.00	129
144	BRITEL33-1053L-5472-ASY55NB	1,830.00	957	176,600.00	261,000.00	143
145	BRITEL33-1053L-5473-ASY55MB	1,830.00	730	206,100.00	304,500.00	166
146	BRITEL33-1053L-5473-ASY55MB	1,830.00	740	223,500.00	330,300.00	180
147	BRITEL33-1053L-5473-ASY55MB	1,830.00	757	217,000.00	320,700.00	175
148	BRITEL33-1053L-5473-ASY55MB	1,830.00	830	193,000.00	285,200.00	156
149	BRITEL33-1053L-5473-ASY55MB	1,830.00	840	206,100.00	304,500.00	166
150	BRITEL33-1053L-5473-ASY55MB	1,830.00	857	206,100.00	304,500.00	166
151	BRITEL33-1053L-5473-ASY55MB	1,830.00	940	159,200.00	235,200.00	129
152	BRITEL33-1053L-5473-ASY55MB	1,830.00	957	176,600.00	261,000.00	143
153	BRITEL33-1053L-7218-SY15	1,830.00	730	206,100.00	304,500.00	166
154	BRITEL33-1053L-7218-SY15	1,830.00	740	223,500.00	330,300.00	180
155	BRITEL33-1053L-7218-SY15	1,830.00	757	217,000.00	320,700.00	175
156	BRITEL33-1053L-7218-SY15	1,830.00	830	193,000.00	285,200.00	156
157	BRITEL33-1053L-7218-SY15	1,830.00	840	206,100.00	304,500.00	166
158	BRITEL33-1053L-7218-SY15	1,830.00	857	206,100.00	304,500.00	166
159	BRITEL33-1053L-7218-SY15	1,830.00	940	159,200.00	235,200.00	129
160	BRITEL33-1053L-7218-SY15	1,830.00	957	176,600.00	261,000.00	143
161	BRITEL33-1053L-7219-SY30	1,830.00	730	206,100.00	304,500.00	166
162	BRITEL33-1053L-7219-SY30	1,830.00	740	223,500.00	330,300.00	180
163	BRITEL33-1053L-7219-SY30	1,830.00	757	217,000.00	320,700.00	175
164	BRITEL33-1053L-7219-SY30	1,830.00	830	193,000.00	285,200.00	156
165	BRITEL33-1053L-7219-SY30	1,830.00	840	206,100.00	304,500.00	166
166	BRITEL33-1053L-7219-SY30	1,830.00	857	206,100.00	304,500.00	166
167	BRITEL33-1053L-7219-SY30	1,830.00	940	159,200.00	235,200.00	129
168	BRITEL33-1053L-7219-SY30	1,830.00	957	176,600.00	261,000.00	143

Generated by wpDataTables

CUTTING-EDGE OPTIC TECHNOLOGY

Maximum Coverage

Perfect, uniform lighting that maximizes the usability of the space and improve users safety.

Focused efficiency

Targeted illumination with customized photometry reduces glare and saves energy resources.

Environmental compliance

Minimize light pollution to comply with local standards and preserve night-time surroundings.

• Enhanced comfort and visibility
• Maximum safety
• Optimized energy consumption and minimal maintenance
• Full compliance with local regulations and sports standards

LED colour temperature

•3000K (Warm White WW 730)
• 3000K (Warm White WW 830)
• 4000K (Neutral White NW 740)
• 4000K (Neutral White NW 840)
• 4000K (Neutral White NW 940)
• 5700K (Cool White NW 757)
• 5700K (Cool White NW 857)
• 5700K (Cool White NW 957)

BRITELINE is a high-power, FIFA Quality Pro Approved floodlighting platform, engineered to
redefine large area illumination with unparalleled efficiency, versatility and precision.
Featuring advanced, modular optical technology, it delivers perfect light distribution with
optimised uniformity and reduced glare, improving visibility and safety across a wide range of areas – such as indoor and as outdoor sports infrastructures, transport terminals, car parks and ports.

• FIFA Quality Pro approved
• Flexibility: modular approach for high-power applications
• Adjustable inclination for optimised photometry and uniformity
• Highly efficient light distributions reduce the quantity of luminaires to be installed
• Reduced Fixture Count and EPA values compared to competitor fixtures
• Excellent uniformity and significant energy savings
• Efficacies up to 180 LPW
• Perfect photometric control avoids any glare or intrusion
• Lightweight, simple and robust design

CERTIFICATIONS

RELATED PRODUCTS

VUE-34X | Spec Sheet

VUE-4R SLS | Spec Sheet

VUE-4 SLS | Spec Sheet

NV-F5-SP | Spec Sheet

BRITELINE Wattage

Briteline Gen 3 Size 1 Lumens

Briteline Gen 3 Size 2 Lumens

BRITELINE GEN3 Size 3 Lumens

CUTTING-EDGE OPTIC TECHNOLOGY

LED colour temperature

CERTIFICATIONS

RELATED PRODUCTS

Intelligent Light + Performance ^®

Menu

LinkedIn

Facebook icon

Instagram

Twitter

BRITELINE Wattage

Briteline Gen 3 Size 1 Lumens

Briteline Gen 3 Size 2 Lumens

BRITELINE GEN3 Size 3 Lumens

CUTTING-EDGE OPTIC TECHNOLOGY

LED colour temperature

CERTIFICATIONS

RELATED PRODUCTS

Intelligent Light + Performance ®

Menu

LinkedIn

Facebook icon

Instagram

Twitter

Intelligent Light + Performance ^®
