  • NV-F5 BUG Ratings

    Generated by wpDataTables
  • NV-F5 Lumens

    Generated by wpDataTables



  • • Ideal for Large Flood and Area Applications: Building Facades, Wall Washes, Up Lighting, , Commercial, Security Lighting, Roadways, and Airports Aprons
    • Sleek Robust Adaptable Design of the NV-F5 (Weight: 44 lbs.) Compliments the Entire Flood Family: NV-F1(up to 6,000 Lumens), NV-F2 (up to 10,000 Lumens), NV-F3 (up to 25,000 Lumens) , and NV-F4 (up to 51,000 Lumens)
    • Distributions Options: 15° Very Narrow, 30° Narrow Beam, 55° Medium Beam, 85° Wide Beam, NEMA 7H x 5V, NEMA 7H x 6V, Forward Throw T4, and Symmetrical T5
    • 256L LED Configurations, 537 to 805 Watts
    • 2700K, 3000K, 3500K, 4000K, 5000K CCT Multichip High Power 70 & 80 CRI LEDs, Static Amber, Red, Green, Blue LEDs as Options
    • IP66 Rated Against Dust & Water Ingress
    • IK10 Rated for Impact Protection, Tamper Proof and Vandal Resistant Options Available
    • Mountings available have a 1.5G to 3G Vibration Rating: Knuckle Mount, Trunnion Mount, and Wall Mount
    • 20kA Surge Protection (120V – 480V), 0 – 10V Programmable, Dimming LED Drivers
    • LED Drivers Ambient Temp. Min (°C) is -40°C and Ambient Temp. Max (°C) ranges to 55°C
    • Silicone Micro Optics providing 96% Clarity and Heat Resistant up to 150°C
    • 9 Standard Finishes, Custom and Marine Grade Finish Available
    • Controls Agnostic, Compatible with Most Control Systems and Sensors
    • Environmentally Friendly Product Which Reduces Energy Consumption, L70 > 100,000 hours
    • Buy America(n) Option Available, Easy to Install Mounting
    • Cost Competitive and Short Shipping Lead Times in Days & Weeks
