  • Related marketing material is available for download or by request for delivery.  Standard shipping is 5-7 business days via UPS Ground. For expedited delivery, please contact factory. Click HERE to order literature.



    Click on image to download!





  • NV-W BUG Ratings Non-Shielded - 16 LED

    Generated by wpDataTables

    NV-W BUG Ratings Non-Shielded - 32 LED

    Generated by wpDataTables

    NV-W BUG Ratings Performance Non-Shielded - 16 LED

    Generated by wpDataTables

    NV-W BUG Ratings Performance Non-Shielded - 32 LED

    Generated by wpDataTables

  • NV-W Wattages

    Order Milliamps 16L 32L
    1.00 400 mA 21w -
    2.00 530 mA 29w -
    3.00 700 mA 37w 71w
    4.00 1000 mA - 100w
    5.00 1050 mA 56w -
    Generated by wpDataTables

    NV-W Lumens Non-Shielded - 16 LED

    Order Model T2 Lumens T2 Lm/W T3 Lumens T3 Lm/W T4 Lumens T4 Lm/W Watts
    1 NV-W-16L-40-27K7 2,561 122 2,591 123 2,561 122 21
    2 NV-W-16L-40-27K8 2,398 114 2,426 116 2,398 114 21
    3 NV-W-16L-40-30K7 2,469 118 2,801 133 2,769 132 21
    4 NV-W-16L-40-30K8 2,571 122 2,601 124 2,571 122 21
    5 NV-W-16L-40-35K8 2,571 122 2,601 124 2,571 122 21
    6 NV-W-16L-40-40K7 2,992 142 3,027 144 2,992 142 21
    7 NV-W-16L-40-40K8 2,769 132 2,801 133 2,769 132 21
    8 NV-W-16L-40-50K7 2,992 142 3,027 144 2,992 142 21
    9 NV-W-16L-40-50K8 2,769 132 2,801 133 2,769 132 21
    10 NV-W-16L-53-30K7 3,544 127 3,579 128 3,544 127 28
    11 NV-W-16L-53-40K7 3,756 134 3,794 136 3,756 134 28
    12 NV-W-16L-53-50K7 3,756 134 3,794 136 3,756 134 28
    13 NV-W-16L-7-30K7 4,388 122 4,432 123 4,388 122 36
    14 NV-W-16L-7-40K7 4,651 129 4,698 131 4,651 129 36
    15 NV-W-16L-7-50K7 4,651 129 4,698 131 4,651 129 36
    16 NV-W-16L-1-30K7 5,970 107 6,029 108 5,970 107 56
    17 NV-W-16L-1-40K7 6,328 113 6,391 114 6,328 113 56
    18 NV-W-16L-1-50K7 6,328 113 6,391 114 6,328 113 56
    Generated by wpDataTables

    NV-W Lumens Non-Shielded - 32 LED

    Order Model T2 Lumens T2 Lm/W T3 Lumens T3 Lm/W T4 Lumens T4 Lm/W Watts
    1 NV-W-32L-7-30K7 9010 127 9100 128 9010 127 71
    2 NV-W-32L-7-40K7 9550 135 9646 136 9550 135 71
    3 NV-W-32L-7-50K7 9550 135 9646 136 9550 135 71
    4 NV-W-32L-1A-30K7 10871 109 10983 110 10871 109 100
    5 NV-W-32L-1A-40K7 11426 114 11544 115 11426 114 100
    6 NV-W-32L-1A-50K7 11426 114 11544 115 11426 114 100
    Generated by wpDataTables

    NV-W Lumens Performance Non-Shielded - 16 LED

    Order Model T4FTW Lumens T4FTW Lm/W Watts
    1 NV-W-16L-40-27K7 2,099 100 21
    2 NV-W-16L-40-30K7 2,437 116 21
    3 NV-W-16L-40-40K7 2,499 119 21
    4 NV-W-16L-40-50K7 2,499 119 21
    5 NV-W-16L-53-27K7 2,587 92 28
    6 NV-W-16L-53-30K7 3,003 107 28
    7 NV-W-16L-53-40K7 3,080 110 28
    8 NV-W-16L-53-50K7 3,080 110 28
    9 NV-W-16L-7-27K7 3,054 85 36
    10 NV-W-16L-7-30K7 3,545 98 36
    11 NV-W-16L-7-40K7 3,636 101 36
    12 NV-W-16L-7-50K7 3,636 101 36
    13 NV-W-16L-1-27K7 4,668 83 56
    14 NV-W-16L-1-30K7 5,418 96 56
    15 NV-W-16L-1-40K7 5,557 99 56
    16 NV-W-16L-1-50K7 5,557 99 56
    Generated by wpDataTables

    NV-W Lumens Performance Non-Shielded - 32 LED

    Order Model T4FTW Lumens T4FTW Lm/W Watts
    1 NV-W-32L-35-27K7 3,901 108 36
    2 NV-W-32L-35-30K7 4,528 126 36
    3 NV-W-32L-35-40K7 4,644 129 36
    4 NV-W-32L-35-50K7 4,644 129 36
    5 NV-W-32L-53-27K7 5,443 101 54
    6 NV-W-32L-53-30K7 6,318 117 54
    7 NV-W-32L-53-40K7 6,480 120 54
    8 NV-W-32L-53-50K7 6,480 120 54
    9 NV-W-32L-7-27K7 6,620 93 71
    10 NV-W-32L-7-30K7 7,684 108 71
    11 NV-W-32L-7-40K7 7,881 111 71
    12 NV-W-32L-7-50K7 7,881 111 71
    13 NV-W-32L-1A-27K7 9,227 91 101
    14 NV-W-32L-1A-30K7 10,709 106 101
    15 NV-W-32L-1A-40K7 10,984 109 101
    16 NV-W-32L-1A-50K7 10,984 109 101
    Generated by wpDataTables

  • – Sleek, low profile housing
    – Spec grade performance
    – Engineered for optimum thermal management
    – Low depreciation rate
    – Reduces energy consumption and costs
    – Light Distributions are Type 2, 3, and 4- Dark Sky compliant—full cut-off design for Commercial applications with stringent property cut-off criteria.
    – Specifically designed for Site / Area applications.
    – Silicone Micro Optics which produce 96% clarity and are rated up to 200° C (50% higher than acrylic)
    – High performance LEDs and Driver combinations for consistency and high reliability
    – Philips Advance 0-10V Dimming Driver technology warranted 5 years—best voltage variance resistance in our industry.
    – Conforms to the strictest Made in America standards. Designed, tooled, fabricated and assembled in the USA
