VSS-1-PM

Slider
  • VALUE SERIES SQUARE: SIZE 1 | PENDANT MOUNT



    – Value Series Square (VSS) is named for its affordable cost and numerous benefits as a long-term lighting solution.
    – Outperforms competitors in wide foot-candles, low energy consumption and lasting durability, even at low wattage.
    – Light Distributions are Type 2, 3, 4, and 5
    – Dark Sky compliant—full cut-off design for Commercial applications with stringent property cut-off criteria.
    – Specifically designed for Site / Area applications including Parking lots and Parking Garages
    – Silicone Micro Optics which produce 96% clarity and are rated up to 200° C (50% higher than acrylic)
    – High performance LEDs and Driver combinations for consistency and high reliability
    – Philips Advance 0-10V Dimming Driver technology warranted 5 years—best voltage variance resistance in our industry.
    – Conforms to the strictest Made in America standards. Designed, tooled, fabricated and assembled in the USA
    View → HID to LED Replacement Guide Sheet [PDF] for quick reference on wattage conversion.

  •



    Introducing the new optical solution to enhance light performance. NLS’ optical systems combined with custom in-house photometric design capabilites, will provide the best optical solution for any application at the lowest cost with the least amount of energy and maintenance.
    – Industry changing optical properties
    – Silicone optic withstands the harshest of weather and dirt conditions
    – Exceptional thermal and UV resistance
    – Rated up to 200°C, whereas acrylic is rated up to 85°C
    – No cracking, yellowing or getting brittle
    – Vandal resistant, no fading or chalking
    – Proven and warranted solution

  • VSS-1 Wattage

    Generated by wpDataTables



    VSS-1 Lumens

    Generated by wpDataTables
  • VSS-1 IES Files

    Order Fixture-Size Type LEDs Milliamps Kelvin Lumens Watts Download File
    1 VSS-1 T2 32L 7 30K 7384 71
    2 VSS-1 T2 32L 7 40K 8023 71
    3 VSS-1 T2 32L 7 50K 8662 71
    4 VSS-1 T2 32L 1 30K 10706 106
    5 VSS-1 T2 32L 1 40K 11660 106
    6 VSS-1 T2 32L 1 50K 12508 106
    7 VSS-1 T2 48L 7 30K 10816 104
    8 VSS-1 T2 48L 7 40K 11752 104
    9 VSS-1 T2 48L 7 50K 12688 104
    10 VSS-1 T2 48L 1 30K 16559 156
    11 VSS-1 T2 48L 1 40K 17160 156
    12 VSS-1 T2 48L 1 50K 18408 156
    13 VSS-1 T2 64L 7 30K 14144 136
    14 VSS-1 T2 64L 7 40K 15368 136
    15 VSS-1 T2 64L 7 50K 16592 136
    16 VSS-1 T2 64L 1 30K 21730 205
    17 VSS-1 T2 64L 1 40K 22550 205
    18 VSS-1 T2 64L 1 50K 24190 205
    19 VSS-1 T3 32L 7 30K 7242 71
    20 VSS-1 T3 32L 7 40K 7952 71
    21 VSS-1 T3 32L 7 50K 8520 71
    22 VSS-1 T3 32L 1 30K 10600 106
    23 VSS-1 T3 32L 1 40K 11554 106
    24 VSS-1 T3 32L 1 50K 12402 106
    25 VSS-1 T3 48L 7 30K 10712 104
    26 VSS-1 T3 48L 7 40K 11648 104
    27 VSS-1 T3 48L 7 50K 12480 104
    28 VSS-1 T3 48L 1 30K 15756 156
    29 VSS-1 T3 48L 1 40K 17004 156
    30 VSS-1 T3 48L 1 50K 18252 156
    31 VSS-1 T3 64L 7 30K 13736 136
    32 VSS-1 T3 64L 7 40K 14824 136
    33 VSS-1 T3 64L 7 50K 16048 136
    34 VSS-1 T3 64L 1 30K 20705 205
    35 VSS-1 T3 64L 1 40K 22345 205
    36 VSS-1 T3 64L 1 50K 23780 205
    37 VSS-1 T4 32L 7 30K 7668 71
    38 VSS-1 T4 32L 7 40K 8307 71
    39 VSS-1 T4 32L 7 50K 8946 71
    40 VSS-1 T4 32L 1 30K 10812 106
    41 VSS-1 T4 32L 1 40K 11766 106
    42 VSS-1 T4 32L 1 50K 12508 106
    43 VSS-1 T4 48L 7 30K 11232 104
    44 VSS-1 T4 48L 7 40K 12168 104
    45 VSS-1 T4 48L 7 50K 13104 104
    46 VSS-1 T4 48L 1 30K 15912 156
    47 VSS-1 T4 48L 1 40K 17316 156
    48 VSS-1 T4 48L 1 50K 18408 156
    49 VSS-1 T4 64L 7 30K 14688 136
    50 VSS-1 T4 64L 7 40K 15912 136
    51 VSS-1 T4 64L 7 50K 17136 136
    52 VSS-1 T4 64L 1 30K 20910 205
    53 VSS-1 T4 64L 1 40K 22755 205
    54 VSS-1 T4 64L 1 50K 24190 205
    55 VSS-1 T5 32L 7 30K 8179 71
    56 VSS-1 T5 32L 7 40K 8946 71
    57 VSS-1 T5 32L 7 50K 9585 71
    58 VSS-1 T5 32L 1 30K 11125 106
    59 VSS-1 T5 32L 1 40K 12190 106
    60 VSS-1 T5 32L 1 50K 13144 106
    61 VSS-1 T5 48L 7 30K 12272 104
    62 VSS-1 T5 48L 7 40K 13312 104
    63 VSS-1 T5 48L 7 50K 14248 104
    64 VSS-1 T5 48L 1 30K 16536 156
    65 VSS-1 T5 48L 1 40K 17940 156
    66 VSS-1 T5 48L 1 50K 19188 156
    67 VSS-1 T5 64L 7 30K 16048 136
    68 VSS-1 T5 64L 7 40K 17408 136
    69 VSS-1 T5 64L 7 50K 18632 136
    70 VSS-1 T5 64L 1 30K 21730 205
    71 VSS-1 T5 64L 1 40K 23575 205
    72 VSS-1 T5 64L 1 50K 25215 205
    Generated by wpDataTables
  •









  • Related marketing material is available for download or by request for delivery.  Standard shipping is 5-7 business days via UPS Ground. For expedited delivery, please contact factory.



    BROCHURE





    View Order






    VSS/VSR PARKING GARAGE BROCHURE





    View Order






    WHY SILICONE OPTICS? TRIFOLD





    View  Order






    VSS | HID TO LED REPLACEMENT CHART





    View
