SEA SIDE BOLLARD

previous arrow
next arrow
previous arrownext arrow
Slider
  • – Features a combination of security, style and vandal resistance that lightens pathways beautifully
    – Light distributes with a Paracline Reflector (PCL), or at 45° a angle by using either the Cut Off Grill (COG45), or Stacked Louver (SL) cast reflectors
    – Available from 17 to 35 watts with Luxeon M Series LEDs
    – The top cast selection offers either Dome or Flat and are available in either 8-inch or 6-inch Round or 8-inch Square
    – Kelvin temperature offering of (warm) 3000, (neutral) 4000 and (cool) 5000
    – Philips Advance 0-10V Dimming Driver technology warranted 5 years
    – Conforms to the strictest Made in America standards. Products are designed, tooled, fabricated and assembled in the USA

  • The Star Power reflector is the best Value LED optical system and utilizes the same mathematical patterns exhibited by millions of stars every night to distribute light to the intended target. Our goal is to create the highest amount of visual acuity and clarity with the least amount of required energy. This is Star Power. This is NLS Lighting.



    starpower_logo

  • Sea Side Bollard Wattage

    Milliamps 16L
    350 mA 17w
    530 mA 26w
    700 mA 35w
    Generated by wpDataTables

    Sea Side Bollard Lumens

    Order Model T5 Lumens T5 LM/W Watts
    1 SSX-X-XX-COG45-16L-35-30K 765 45 17
    2 SSX-X-XX-COG45-16L-35-40K 850 50 17
    3 SSX-X-XX-COG45-16L-35-50K 935 55 17
    4 SSX-X-XX-COG45-16L-53-30K 1,170 45 26
    5 SSX-X-XX-COG45-16L-53-40K 1,300 50 26
    6 SSX-X-XX-COG45-16L-53-50K 1,430 55 26
    7 SSX-X-XX-COG45-16L-7-30K 1,575 45 35
    8 SSX-X-XX-COG45-16L-7-40K 1,750 50 35
    9 SSX-X-XX-COG45-16L-7-50K 1,925 55 35
    10 SSX-X-XX-SL-16L-35-30K 986 58 17
    11 SSX-X-XX-SL-16L-35-40K 1,054 62 17
    12 SSX-X-XX-SL-16L-35-50K 1,105 65 17
    13 SSX-X-XX-SL-16L-53-30K 1,508 58 26
    14 SSX-X-XX-SL-16L-53-40K 1,612 62 26
    15 SSX-X-XX-SL-16L-53-50K 1,690 65 26
    16 SSX-X-XX-SL-16L-7-30K 2,030 58 35
    17 SSX-X-XX-SL-16L-7-40K 2,170 62 35
    18 SSX-X-XX-SL-16L-7-50K 2,275 65 35
    19 SSX-X-XX-PR-16L-35-30K 1,309 77 17
    20 SSX-X-XX-PR-16L-35-40K 1,377 81 17
    21 SSX-X-XX-PR-16L-35-50K 1,428 84 17
    22 SSX-X-XX-PR-16L-53-30K 2,002 77 26
    23 SSX-X-XX-PR-16L-53-40K 2,106 81 26
    24 SSX-X-XX-PR-16L-53-50K 2,184 84 26
    25 SSX-X-XX-PR-16L-7-30K 2,695 77 35
    26 SSX-X-XX-PR-16L-7-40K 2,835 81 35
    27 SSX-X-XX-PR-16L-7-50K 2,975 85 35
    Generated by wpDataTables
  • Download Complete Zipped IES Files

    All Sea Side Bollard IES Files



    Sea Side Bollard IES Files

    Fixture-Size Optic Type Shaft-Size LEDs Milliamps Kelvin Lumens System Watts Download File
    SSX-2 COG45 6R 16L 35 30K 765 17
    SSX-2 COG45 6R 16L 35 40K 850 17
    SSX-2 COG45 6R 16L 35 50K 935 17
    SSX-2 COG45 6R 16L 53 30K 1170 26
    SSX-2 COG45 6R 16L 53 40K 1300 26
    SSX-2 COG45 6R 16L 53 50K 1430 26
    SSX-2 COG45 6R 16L 7 30K 1575 35
    SSX-2 COG45 6R 16L 7 40K 1750 35
    SSX-2 COG45 6R 16L 7 50K 1925 35
    SSX-3 COG45 6R 16L 35 30K 765 17
    SSX-3 COG45 6R 16L 35 40K 850 17
    SSX-3 COG45 6R 16L 35 50K 935 17
    SSX-3 COG45 6R 16L 53 30K 1170 26
    SSX-3 COG45 6R 16L 53 40K 1300 26
    SSX-3 COG45 6R 16L 53 50K 1430 26
    SSX-3 COG45 6R 16L 7 30K 1575 35
    SSX-3 COG45 6R 16L 7 40K 1750 35
    SSX-3 COG45 6R 16L 7 50K 1925 35
    SSX-4 COG45 6R 16L 35 30K 765 17
    SSX-4 COG45 6R 16L 35 40K 850 17
    SSX-4 COG45 6R 16L 35 50K 935 17
    SSX-4 COG45 6R 16L 53 30K 1170 26
    SSX-4 COG45 6R 16L 53 40K 1300 26
    SSX-4 COG45 6R 16L 53 50K 1430 26
    SSX-4 COG45 6R 16L 7 30K 1575 35
    SSX-4 COG45 6R 16L 7 40K 1750 35
    SSX-4 COG45 6R 16L 7 50K 1925 35
    SSX-2 COG45 8R 16L 35 30K 765 17
    SSX-2 COG45 8R 16L 35 40K 850 17
    SSX-2 COG45 8R 16L 35 50K 935 17
    SSX-2 COG45 8R 16L 53 30K 1170 26
    SSX-2 COG45 8R 16L 53 40K 1300 26
    SSX-2 COG45 8R 16L 53 50K 1430 26
    SSX-2 COG45 8R 16L 7 30K 1575 35
    SSX-2 COG45 8R 16L 7 40K 1750 35
    SSX-2 COG45 8R 16L 7 50K 1925 35
    SSX-3 COG45 8R 16L 35 30K 765 17
    SSX-3 COG45 8R 16L 35 40K 850 17
    SSX-3 COG45 8R 16L 35 50K 935 17
    SSX-3 COG45 8R 16L 53 30K 1170 26
    SSX-3 COG45 8R 16L 53 40K 1300 26
    SSX-3 COG45 8R 16L 53 50K 1430 26
    SSX-3 COG45 8R 16L 7 30K 1575 35
    SSX-3 COG45 8R 16L 7 40K 1750 35
    SSX-3 COG45 8R 16L 7 50K 1925 35
    SSX-4 COG45 8R 16L 35 30K 765 17
    SSX-4 COG45 8R 16L 35 40K 850 17
    SSX-4 COG45 8R 16L 35 50K 935 17
    SSX-4 COG45 8R 16L 53 30K 1170 26
    SSX-4 COG45 8R 16L 53 40K 1300 26
    SSX-4 COG45 8R 16L 53 50K 1430 26
    SSX-4 COG45 8R 16L 7 30K 1575 35
    SSX-4 COG45 8R 16L 7 40K 1750 35
    SSX-4 COG45 8R 16L 7 50K 1925 35
    SSX-2 COG45 8S 16L 35 30K 765 17
    SSX-2 COG45 8S 16L 35 40K 850 17
    SSX-2 COG45 8S 16L 35 50K 935 17
    SSX-2 COG45 8S 16L 53 30K 1170 26
    SSX-2 COG45 8S 16L 53 40K 1300 26
    SSX-2 COG45 8S 16L 53 50K 1430 26
    SSX-2 COG45 8S 16L 7 30K 1575 35
    SSX-2 COG45 8S 16L 7 40K 1750 35
    SSX-2 COG45 8S 16L 7 50K 1925 35
    SSX-3 COG45 8S 16L 35 30K 765 17
    SSX-3 COG45 8S 16L 35 40K 850 17
    SSX-3 COG45 8S 16L 35 50K 935 17
    SSX-3 COG45 8S 16L 53 30K 1170 26
    SSX-3 COG45 8S 16L 53 40K 1300 26
    SSX-3 COG45 8S 16L 53 50K 1430 26
    SSX-3 COG45 8S 16L 7 30K 1575 35
    SSX-3 COG45 8S 16L 7 40K 1750 35
    SSX-3 COG45 8S 16L 7 50K 1925 35
    SSX-4 COG45 8S 16L 35 30K 765 17
    SSX-4 COG45 8S 16L 35 40K 850 17
    SSX-4 COG45 8S 16L 35 50K 935 17
    SSX-4 COG45 8S 16L 53 30K 1170 26
    SSX-4 COG45 8S 16L 53 40K 1300 26
    SSX-4 COG45 8S 16L 53 50K 1430 26
    SSX-4 COG45 8S 16L 7 30K 1575 35
    SSX-4 COG45 8S 16L 7 40K 1750 35
    SSX-4 COG45 8S 16L 7 50K 1925 35
    SSX-2 SL 6R 16L 35 30K 765 17
    SSX-2 SL 6R 16L 35 40K 850 17
    SSX-2 SL 6R 16L 35 50K 935 17
    SSX-2 SL 6R 16L 53 30K 1170 26
    SSX-2 SL 6R 16L 53 40K 1300 26
    SSX-2 SL 6R 16L 53 50K 1430 26
    SSX-2 SL 6R 16L 7 30K 1575 35
    SSX-2 SL 6R 16L 7 40K 1750 35
    SSX-2 SL 6R 16L 7 50K 1925 35
    SSX-3 SL 6R 16L 35 30K 765 17
    SSX-3 SL 6R 16L 35 40K 850 17
    SSX-3 SL 6R 16L 35 50K 935 17
    SSX-3 SL 6R 16L 53 30K 1170 26
    SSX-3 SL 6R 16L 53 40K 1300 26
    SSX-3 SL 6R 16L 53 50K 1430 26
    SSX-3 SL 6R 16L 7 30K 1575 35
    SSX-3 SL 6R 16L 7 40K 1750 35
    SSX-3 SL 6R 16L 7 50K 1925 35
    SSX-4 SL 6R 16L 35 30K 765 17
    SSX-4 SL 6R 16L 35 40K 850 17
    SSX-4 SL 6R 16L 35 50K 935 17
    SSX-4 SL 6R 16L 53 30K 1170 26
    SSX-4 SL 6R 16L 53 40K 1300 26
    SSX-4 SL 6R 16L 53 50K 1430 26
    SSX-4 SL 6R 16L 7 30K 1575 35
    SSX-4 SL 6R 16L 7 40K 1750 35
    SSX-4 SL 6R 16L 7 50K 1925 35
    SSX-2 SL 8R 16L 35 30K 765 17
    SSX-2 SL 8R 16L 35 40K 850 17
    SSX-2 SL 8R 16L 35 50K 935 17
    SSX-2 SL 8R 16L 53 30K 1170 26
    SSX-2 SL 8R 16L 53 40K 1300 26
    SSX-2 SL 8R 16L 53 50K 1430 26
    SSX-2 SL 8R 16L 7 30K 1575 35
    SSX-2 SL 8R 16L 7 40K 1750 35
    SSX-2 SL 8R 16L 7 50K 1925 35
    SSX-3 SL 8R 16L 35 30K 765 17
    SSX-3 SL 8R 16L 35 40K 850 17
    SSX-3 SL 8R 16L 35 50K 935 17
    SSX-3 SL 8R 16L 53 30K 1170 26
    SSX-3 SL 8R 16L 53 40K 1300 26
    SSX-3 SL 8R 16L 53 50K 1430 26
    SSX-3 SL 8R 16L 7 30K 1575 35
    SSX-3 SL 8R 16L 7 40K 1750 35
    SSX-3 SL 8R 16L 7 50K 1925 35
    SSX-4 SL 8R 16L 35 30K 765 17
    SSX-4 SL 8R 16L 35 40K 850 17
    SSX-4 SL 8R 16L 35 50K 935 17
    SSX-4 SL 8R 16L 53 30K 1170 26
    SSX-4 SL 8R 16L 53 40K 1300 26
    SSX-4 SL 8R 16L 53 50K 1430 26
    SSX-4 SL 8R 16L 7 30K 1575 35
    SSX-4 SL 8R 16L 7 40K 1750 35
    SSX-4 SL 8R 16L 7 50K 1925 35
    SSX-2 SL 8S 16L 35 30K 765 17
    SSX-2 SL 8S 16L 35 40K 850 17
    SSX-2 SL 8S 16L 35 50K 935 17
    SSX-2 SL 8S 16L 53 30K 1170 26
    SSX-2 SL 8S 16L 53 40K 1300 26
    SSX-2 SL 8S 16L 53 50K 1430 26
    SSX-2 SL 8S 16L 7 30K 1575 35
    SSX-2 SL 8S 16L 7 40K 1750 35
    SSX-2 SL 8S 16L 7 50K 1925 35
    SSX-3 SL 8S 16L 35 30K 765 17
    SSX-3 SL 8S 16L 35 40K 850 17
    SSX-3 SL 8S 16L 35 50K 935 17
    SSX-3 SL 8S 16L 53 30K 1170 26
    SSX-3 SL 8S 16L 53 40K 1300 26
    SSX-3 SL 8S 16L 53 50K 1430 26
    SSX-3 SL 8S 16L 7 30K 1575 35
    SSX-3 SL 8S 16L 7 40K 1750 35
    SSX-3 SL 8S 16L 7 50K 1925 35
    SSX-4 SL 8S 16L 35 30K 765 17
    SSX-4 SL 8S 16L 35 40K 850 17
    SSX-4 SL 8S 16L 35 50K 935 17
    SSX-4 SL 8S 16L 53 30K 1170 26
    SSX-4 SL 8S 16L 53 40K 1300 26
    SSX-4 SL 8S 16L 53 50K 1430 26
    SSX-4 SL 8S 16L 7 30K 1575 35
    SSX-4 SL 8S 16L 7 40K 1750 35
    SSX-4 SL 8S 16L 7 50K 1925 35
    SSX-2 PR 6R 16L 35 30K 765 17
    SSX-2 PR 6R 16L 35 40K 850 17
    SSX-2 PR 6R 16L 35 50K 935 17
    SSX-2 PR 6R 16L 53 30K 1170 26
    SSX-2 PR 6R 16L 53 40K 1300 26
    SSX-2 PR 6R 16L 53 50K 1430 26
    SSX-2 PR 6R 16L 7 30K 1575 35
    SSX-2 PR 6R 16L 7 40K 1750 35
    SSX-2 PR 6R 16L 7 50K 1925 35
    SSX-3 PR 6R 16L 35 30K 765 17
    SSX-3 PR 6R 16L 35 40K 850 17
    SSX-3 PR 6R 16L 35 50K 935 17
    SSX-3 PR 6R 16L 53 30K 1170 26
    SSX-3 PR 6R 16L 53 40K 1300 26
    SSX-3 PR 6R 16L 53 50K 1430 26
    SSX-3 PR 6R 16L 7 30K 1575 35
    SSX-3 PR 6R 16L 7 40K 1750 35
    SSX-3 PR 6R 16L 7 50K 1925 35
    SSX-4 PR 6R 16L 35 30K 765 17
    SSX-4 PR 6R 16L 35 40K 850 17
    SSX-4 PR 6R 16L 35 50K 935 17
    SSX-4 PR 6R 16L 53 30K 1170 26
    SSX-4 PR 6R 16L 53 40K 1300 26
    SSX-4 PR 6R 16L 53 50K 1430 26
    SSX-4 PR 6R 16L 7 30K 1575 35
    SSX-4 PR 6R 16L 7 40K 1750 35
    SSX-4 PR 6R 16L 7 50K 1925 35
    SSX-2 PR 8R 16L 35 30K 765 17
    SSX-2 PR 8R 16L 35 40K 850 17
    SSX-2 PR 8R 16L 35 50K 935 17
    SSX-2 PR 8R 16L 53 30K 1170 26
    SSX-2 PR 8R 16L 53 40K 1300 26
    SSX-2 PR 8R 16L 53 50K 1430 26
    SSX-2 PR 8R 16L 7 30K 1575 35
    SSX-2 PR 8R 16L 7 40K 1750 35
    SSX-2 PR 8R 16L 7 50K 1925 35
    SSX-3 PR 8R 16L 35 30K 765 17
    SSX-3 PR 8R 16L 35 40K 850 17
    SSX-3 PR 8R 16L 35 50K 935 17
    SSX-3 PR 8R 16L 53 30K 1170 26
    SSX-3 PR 8R 16L 53 40K 1300 26
    SSX-3 PR 8R 16L 53 50K 1430 26
    SSX-3 PR 8R 16L 7 30K 1575 35
    SSX-3 PR 8R 16L 7 40K 1750 35
    SSX-3 PR 8R 16L 7 50K 1925 35
    SSX-4 PR 8R 16L 35 30K 765 17
    SSX-4 PR 8R 16L 35 40K 850 17
    SSX-4 PR 8R 16L 35 50K 935 17
    SSX-4 PR 8R 16L 53 30K 1170 26
    SSX-4 PR 8R 16L 53 40K 1300 26
    SSX-4 PR 8R 16L 53 50K 1430 26
    SSX-4 PR 8R 16L 7 30K 1575 35
    SSX-4 PR 8R 16L 7 40K 1750 35
    SSX-4 PR 8R 16L 7 50K 1925 35
    SSX-2 PR 8S 16L 35 30K 765 17
    SSX-2 PR 8S 16L 35 40K 850 17
    SSX-2 PR 8S 16L 35 50K 935 17
    SSX-2 PR 8S 16L 53 30K 1170 26
    SSX-2 PR 8S 16L 53 40K 1300 26
    SSX-2 PR 8S 16L 53 50K 1430 26
    SSX-2 PR 8S 16L 7 30K 1575 35
    SSX-2 PR 8S 16L 7 40K 1750 35
    SSX-2 PR 8S 16L 7 50K 1925 35
    SSX-3 PR 8S 16L 35 30K 765 17
    SSX-3 PR 8S 16L 35 40K 850 17
    SSX-3 PR 8S 16L 35 50K 935 17
    SSX-3 PR 8S 16L 53 30K 1170 26
    SSX-3 PR 8S 16L 53 40K 1300 26
    SSX-3 PR 8S 16L 53 50K 1430 26
    SSX-3 PR 8S 16L 7 30K 1575 35
    SSX-3 PR 8S 16L 7 40K 1750 35
    SSX-3 PR 8S 16L 7 50K 1925 35
    SSX-4 PR 8S 16L 35 30K 765 17
    SSX-4 PR 8S 16L 35 40K 850 17
    SSX-4 PR 8S 16L 35 50K 935 17
    SSX-4 PR 8S 16L 53 30K 1170 26
    SSX-4 PR 8S 16L 53 40K 1300 26
    SSX-4 PR 8S 16L 53 50K 1430 26
    SSX-4 PR 8S 16L 7 30K 1575 35
    SSX-4 PR 8S 16L 7 40K 1750 35
    SSX-4 PR 8S 16L 7 50K 1925 35
    Generated by wpDataTables
  •





    Available Configurations – mix and match!





  • Related marketing material is available for download or by request for delivery.  Standard shipping is 5-7 business days via UPS Ground. For expedited delivery, please contact factory.
